Version 3.05 of the PASSAT program has been released, containing a number of additional calculations, corrections and features:

1. calculation of non-circular cross-section elements (rectangular, oval, rounded, with partitions) according to ASME VIII-1 App.13;
2. possibility of modeling and analysis of tank frame roofs:
• a visual designer of the beam frame has been developed;
• an algorithm has been developed for the automatic generation of a beam-shell fi-nite element model of a tank, including a roof frame, flooring, support columns, and a wall with stiffening rings;
• an algorithm has been developed for automatically loading the finite element model of the tank with loads from its own weight of elements, snow, wind, equipment, external and internal pressure, hydrostatic pressure, according to the recommendations of the API-650;
• a module for exporting a finite element tank model to the ANSYS program using the APDL format has been developed;
3. calculation of bellows compensator according to EN 13445-3, EN 14917;
4. calculation of the flange connection according to EN 13445-3;
5. added a new element – a round lid with a large central hole (calculated according to ASME VIII-1);
6. redesigned and updated export-import to an open format (XML converter);
7. etc.

Read more…

All users who are under warranty are recommended to install this version of the program.

Start-Prof version 4.85 R6 release.

Changes

The Start-Prof users with active maintenance may download the new version from download page. To upgrade the current version the dongle updating is not needed.

Start-Prof version 4.85 R5 release. Changes

The Start-Prof users with active maintenance may download the new version from download page. To upgrade the current version the dongle updating is not needed.

New version released Nozzle-FEM 3.3 significantly expands the program capabilities:

1. the fatigue assessment as per ASME BPVC.VIII.2-2019 and capability to set design and operating loads were added;
2. the import of PASS/EQUIP XML files was added;
3. the spherical unbeaded head (cover) model was added;
4. postprocessor capabilities were expanded, including display of specified loads;
5. capabilities of RTF report generator were expanded;
6. the program manual was significantly redesigned;
7. other improvements and fixes.

Read more...

All users under technical support are recommended to install this program version.

On December 24, 2020 the final meeting of the Interdepartmental Council of the National Quality Infrastructure was held, with the Chairman of State Secretary - Deputy Minister of Economic Development of the Russian Federation - Alexei Khersontsev. The main issues discussed at the meeting were the requalification of accredited persons for conformity with the criteria established by the Government of the Russian Federation for inclusion in the National Part of the EAEU Unified Register, and summing up the implementation of the Russian Government Decree No. 1236 dated September 21, 2019.

As a result of meetings of the Interdepartmental Council, a positive decision was taken to requalify the CB NTP Truboprovod for inclusion in the National Part of the EAEU Unified Register.

Start-Prof version 4.84 R3 release. Changes:

1. Updated code ASME B31.5-2019 Refrigeration Piping and Heat Transfer Components (USA);
2. Updated code ASME B31.12-2019 Hydrogen Piping and Pipelines (USA);
3. Added Pipes, Tees, Bends and Reducers properties according to the EN codes: EN 10216-1:2013, EN 10216-2:2013, EN 10216-3:2013, EN 10216-42013, EN 10216-5:2013, EN 10217-1:2019, EN 10217-2:2019, EN 10217-3:2019, EN 10217-4:2019, EN 10217-5:2019, EN 10217-6:2019, EN 10217-7:2019, EN 10253-1:1999, EN 10253-2:2007, EN 10253-3:2008, EN 10253-4:2008;
4. Added the short description of PASS/START-PROF COM Interface that allows for side applications on C#, Basic and other programming languages to create, modify and analyze models using START-PROF and read the analysis results. It is used for creation of plug-ins for START-PROF software. Full description available upon request. For example, the following plugins was written using the PASS/START-PROF COM-Interface;
5. Export to PCF, Import from PCF, Export to CAESAR II, Import from CAESAR II, Import from PDMS, QA (quality assurance) software, that automatically analyze a lot of models and compare results with previous versions. Any company can create an own plugin for seamless integration of PASS/START-PROF software into company’s workflow. It is possible to write a plugin that will automatically invoke PASS/START-PROF stress analysis from 3D modeling software in background and transfer the analysis results back or generate the reports following the corporate templates. Also it allows creating a plugin for data conversion between PASS/START-PROF and any other software. Furthermore, the plugin for piping model optimization or running complex sequences of parametric model piping stress analysis can be created;
6. Added ability to import the model from Excel Spreadsheet. It can be used to import the model geometry from manually created spreadsheet;
7. Added ability to import the model using data extraction from AutoCAD. It can be used to import the piping geometry from Autocad;
8. Added ability to specify the stiffening rings on the pipe element, that is used for vacuum piping buckling analysis;
9. Added ability to put the miter joints on the ends of the bend elements and other fittings;
10. Added ability to set the turbine, compressor, pump, and nozzle movements manually if they are provided by manufacturer;
11. Added new codes SNiP III-42-80* and SP 86.13330.2014 for construction stage of pipelines;
12. Pipe database is updated with the latest version of ASME B36.19M-2018;
13. EN 13941: Now using the effective axial force instead of true axial force during stress calculation;
14. Removed restriction to specify different pressures and temperatures on the pipes, connected to the fittings (tees, bends, reducers). Now the greatest temperature and greatest pressure are used for fittings wall thickness check, SIF and k-factor calculation (if required by specific code);
15. Built-in calculator is added to the more fields of user interface;
16. Added ability to switch between neighboring pipe objects without closing the dialog;
17. Added ability to check the angle of any bend. Added ability to see and modify the long-radius bend tangent;
18. Fixed minor issues and made improvements reported by users (60+);
19. More details here.

The Start-Prof users with valid warranty may download the new version from download page). To upgrade the current version the dongle updating is not needed.

PASS/START-PROF Team announces release of 4.84 R3 version.

The most important changes implemented in PASS/START-PROF 4.84 R3 are listed below:

1. Added ISOPLUS Polyurethane Pre-insulated Pipe Jacket Sizes Database for district heating and district cooling network (Standard, 1x reinforced, 2x reinforced);
2. Added INPAL (Solice) Polyurethane Pre-insulated Pipe Jacket Sizes Database for district heating and district cooling network (Isolation Standard, Isolation +, Isolation ++);
3. Added export to CAESAR II neutral file (.cii);
4. Added export to PCF (.pcf) file;
5. Ability to add any number of nozzles to the turbine and compressor objects is implemented;
6. Removed hoop tangent stress check in insulation for the EN 13941 code;
7. Added function to replace the flange with a rigid element;
8. Added new analysis types for EN 13941 code;
9. Added the ability to choose density of product, insulation, cladding, and lining from the menu;
10. Added graphic representation of the soil movements in horizontal direction;
11. Fixed all bugs reported by users.

To learn about all changes, please visit the product history section.

All PASS/START-PROF users with active Maintenance Support are recommended to download the latest software version (dongle update is not required).

Start-Prof version 4.84 R2 release. Changes:

1. Fixed the file corruption during saving if hit twice the save button;
2. Added function to copy the Pipe List into clipboard. You can paste it into MS EXCEL;
3. Added material PE 4710 to the thermoplastic database;
4. Improved properties of PE-RT II material down to -30\( ^oC \) and up to 95\( ^oC \);
5. Fixed some bugs.

The Start-Prof users with valid warranty may download the new version from download page. To upgrade the current version the dongle updating is not needed.

New version of PASS/EQUIP Nozzle-FEM 3.2 is released. It expands the program capabilities:

1. The new models was added – bend (elbow) with nozzle , bend support, conical skirt of column support with opening;



2. The additional sections to runhead pipe was added;
3. The non-circle nozzle shapes, the load application in WRC 107/297 designations were added;
4. The program manual was significantly redesigned;
5. Other improvements and fixes.

Read more...

All users under technical support are recommended to install this program version.

New version Nozzle-FEM 3.1 expands the program capabilities:

1. The new models was added – torispherical head, conical reducer and head with a knuckle\flare, support skirt;



2. The calculations in testing and mounting conditions were added for all codes;
3. The capability of axial direction (axis Z) of head and rectangle plate inverting was added;
4. Other improvements and fixes.

Read more...

All users under technical support are recommended to install this program version.
